Seberapa Banyak yang Anda Ketahui Tentang Pengklasifikasi Spiral Untuk Mengklasifikasikan Peralatan?

Pengklasifikasi Spiral

The pengklasifikasi spiral is primarily used in mineral processing to separate materials based on particle size by utilizing a rotating spiral screw within an inclined trough, where larger particles settle to the bottom and are carried upwards by the spiral, while finer particles overflow with the water at the lower end; essentially, it classifies materials based on their settling velocity in a water slurry, with coarser particles being separated from finer ones.

Keuntungan Pengklasifikasi Spiral

• Pasir yang dikembalikan secara otomatis diangkat ke ketinggian tertentu dan kemudian langsung dikembalikan ke ujung pengumpanan pabrik bolasehingga tidak perlu lagi menggunakan pengumpan gabungan dan sangat menghemat investasi dalam peralatan dan konstruksi sipil;
• Kontinuitas dan stabilitas pengembalian pasir serta konsentrasi pengembalian pasir yang tinggi kondusif untuk meningkatkan konsentrasi bijih gerinda, dan dengan demikian meningkatkan efisiensi penggilingan;
• Ukuran gradasi dapat dikontrol sesuai dengan jumlah pengumpanan yang berbeda dan konsentrasi luapan;
• Struktur sederhana, pengoperasian dan manajemen yang mudah, pengoperasian yang andal, dan biaya perawatan yang rendah.

Jenis Pengklasifikasi Spiral

(1) According to the overflow weir height

According to the overflow weir height, that is, the position of the spiral in the flume is different from the height of the slurry surface, the spiral classifier can be divided into three types: tipe bendung tinggi, tipe bendung rendah, dan tipe tenggelam.

• Pengklasifikasi spiral bendung tinggi
  The overflow weir of a high-weir spiral classifier is generally positioned above the lower bearing center of the spiral shaft and below the upper edge of the spiral at the overflow end. Compared with a low-weir design, the high-weir classifier provides a larger settling area. The overflow weir height can also be adjusted within a certain range, allowing the effective settling area to be modified according to classification requirements. High-weir spiral classifiers are generally suitable for relatively coarse classification. They are often used in the first stage of grinding, particularly when the required separation size is relatively coarse.
• Lpengklasifikasi spiral bendung
  The overflow weir of a low-weir spiral classifier is generally lower than the center of the overflow-end bearing. Consequently, its effective settling area is relatively small, and its overflow capacity is limited. The strong agitation generated by the spiral can also disturb the slurry surface. Therefore, low-weir spiral classifiers are generally not the preferred option for fine grinding classification. They are more commonly used for coarse ore washing, desliming, or dewatering applications involving relatively low mud content, depending on the specific process requirements.
• Spengklasifikasi spiral terendam
  In a submerged spiral classifier, several turns of the spiral blades at the overflow end are completely submerged below the slurry surface. This creates a relatively large and deep settling area. Because the classification zone is deeper and the slurry surface is relatively stable, submerged spiral classifiers are suitable for finer classification.

Due to the difference in structure between the high weir type and submerged spiral classifier, the two play different roles in grading operations. The high weir spiral classifier is more suitable for separating coarse grains with a particle size larger than 0.15mm, often used in the first stage of milling; while the submerged spiral classifier is more suitable for separating overflow products with a particle size smaller than 0.15mm due to its smooth grading surface, high overflow yield, and fine particle size, often used in the second stage of milling to form a joint unit with the mill.

(2) According to the number of spiral shafts

Menurut jumlah poros spiral, pengklasifikasi spiral dapat dibagi menjadi spiral tunggal dan spiral ganda. The grading performance of the two is the same, but the double spiral classifier in the sand processing capacity, overflow processing capacity, and the same specification spiral diameter are significantly larger than the single spiral classifier. The price of the double spiral classifier is much higher than that of the single spiral classifier. So it is more suitable for large-scale milling machines with the use.

Mineral processing experts suggest that the single spiral classifier should be used as much as possible under the determined processing capacity. According to statistics, the spiral working load of the double spiral classifier is 0.6-0.75 times that of the single spiral classifier, and the efficiency is relatively low. Therefore, when choosing the spiral classifier, it is necessary to determine its appropriate spiral speed and number according to the processing capacity.

Kesimpulan

Spiral classifiers remain an important type of classification equipment in mineral processing plants. Although hydrocyclones have become increasingly common because of their compact footprint and strong fine-classification capability, spiral classifiers continue to offer advantages in grinding circuits that require stable coarse-particle return, simple operation, and reliable mechanical classification.

High-weir, low-weir, and submerged spiral classifiers have different structural characteristics and applications. Likewise, single-spiral and double-spiral models differ mainly in processing capacity and equipment investment.

Therefore, there is no universally optimal classification equipment for every pabrik pengolahan mineral. The best choice depends on ore properties, target particle size, processing capacity, grinding circuit configuration, slurry conditions, plant layout, and economic considerations.

For mineral processing plants, the key is to understand the working principle and application characteristics of each classification equipment type and then select the most appropriate solution according to actual production requirements. Proper classification can reduce unnecessary overgrinding, improve grinding efficiency, stabilize the beneficiation feed, and ultimately contribute to better overall plant performance.
