How to Effectively Separate Scheelite And Fluorite Ore?

With fluorite prices rising amid growing industrial demand, its value now rivals scheelite—yet 43% of China’s fluorite reserves exist as associated minerals with low utilization rates. Scheelite and fluorite minerals share similar properties, making separation tricky. We understand your frustration—improper methods lead to poor recovery rates and wasted resources.

The most effective method involves a combination of gravity separation and flotation. Scheelite has higher specific gravity than fluorite, allowing initial separation through shaking tables or spirals. Then, selective flotation using fatty acid collectors and sodium silicate depressants targets scheelite while suppressing fluorite. Proper pH control (around 9-10) is critical for success.

Now that we’ve outlined the basic approach, we detail targeted methods for each mineral.

The Beneficiation Method of Scheelite

A scheelite tem uma boa capacidade de flutuação e é frequentemente tratada por o método combinado de separação por gravidade e flotação.

A separação por flotação da scheelite resolve principalmente o problema da separação de minérios de sulfureto e minérios não metálicos, especificamente:

• Separation of scheelite from sulfide ore. Xanthate is used to capture sulfide minerals before flotation of scheelite. When floating scheelite, add a small amount of oxide and sodium sulfide to suppress a small amount of sulfide that has not been floated.
• Separation of scheelite from calcite and fluorite. Commonly used thick slurry high temperature method. First concentrate the pulp to a concentration of 60~70%, then add water glass, heat the pulp to above 80°C, stir for 30-60 minutes, then dilute with water, and float scheelite at room temperature. The product in the tank is Fluorite and calcite.
• Separation of scheelite from quartz-like silicates. Using oleic acid as a collector and water glass as an inhibitor can inhibit quartz and silicate gangue and float scheelite.
• Separation of scheelite and barite. Because water glass has similar inhibitory effects on scheelite and barite, it is difficult to separate water glass alone, and it is necessary to use alkyl sulfate or sulfonate as a collector to reverse-float barite under the condition of pH=1.5-3.0; scheelite is obtained in the tank.
• Separação de tungsténio e estanho. A seleção eléctrica e a flotação também podem ser utilizadas. Durante separação por flotaçãoA scheelite é recolhida com ácido gordo e a cassiterite é suprimida com vidro de água. Separação do tungsténio e do molibdénio. O molibdénio é flutuado primeiro, depois a scheelite é flutuada com ácido oleico, e uma grande quantidade de vidro de água é usada para aquecer e selecionar a scheelite.

Commonly used collectors for scheelite are oleic acid, oleic acid soap, and 731 oxide paraffin soap. There was once a beneficiation plant that used high-temperature beneficiation to select scheelite. The production technical indicators: the grade of scheelite concentrate was 67.03%, the tailings were 0.095%, and the recovery rate was 80.17%.

The Beneficiation Methods and Beneficiation Equipment of Fluorite Ore

Fluorite is mainly composed of calcium fluoride, which is an important metallurgical flux and chemical raw material. As a mineral resource, what are the beneficiation methods and beneficiation equipment of fluorite ore?

A. Fluorite Ore Beneficiation

Fluorite ore beneficiation mainly adopts the flotation method and gravity separation method. The flotation method is used to deal with fine-grained dissemination and low-grade fluorite ore. It is also one of the most important beneficiation methods for fluorite ore beneficiation. The only way to get fluorite ore powder. Gravity separation is used to process the beneficiation and purification of coarse-grained embedded high-grade fluorite ore to obtain coarse-grained metallurgical-grade fluorite lump ore, which is the main method for producing fluorite concentrate for the steelmaking industry.

• Método de flotação: High-quality fluorite concentrate powder can be obtained by flotation treatment of fluorite ore, but the investment in equipamento de flotação is large, the operating cost is high, and it has certain pollution to the environment. Therefore, under the premise that environmental protection requirements are becoming more and more strict today, the application of fluorite ore flotation is more and more limited, which also promotes the improvement and application of fluorite ore gravity separation technology and equipment to some extent.
• Separação por gravidade has a very good effect on the purification of coarse-grained embedded fluorite ore. Under normal circumstances, gravity separation can also be used for beneficiation and purification of fine-grained fluorite ore, which has the advantages of energy saving, high efficiency, and environmental protection. In the new type of fluorite beneficiation plant, the application of the gravity separation method has gradually surpassed the flotation method.

B. Mineral Processing Method

• Método de separação por gravidade: O método de separação por gravidade é adequado para o tratamento de minério granulado de fluorite de grão grosso e de alta qualidade, e também tem um bom efeito na beneficiação de algum minério de fluorite de grão fino. Existem instalações de separação por gravidade de minério de fluorite em Xinyang, Henan, Zhenglanqi, Mongólia Interior, Jinchang, Gansu, e Wuchuan, Guizhou.
• Método de flotação: O método de flotação é adequado para o beneficiamento de minério de fluorita de baixo grau disseminado de granulação fina, e seu concentrado é usado principalmente para a produção de ácido fluorídrico na indústria química. O número de equipamentos seleccionados no equipamento de flotação de pedra aumenta, e o investimento em equipamento aumenta. O método de flotação tem uma certa poluição para o ambiente e muitas regiões proibiram a utilização do método de flotação para selecionar a fluorite.

C. Gravity Beneficiation Equipment

The gravity separation method is mainly used for the beneficiation and purification of coarse-grained embedded fluorite ore. Therefore, the equipamento de separação por gravidade for fluorite ore is mostly gabarito concentrador. O beneficiamento e a purificação do minério de fluorita têm bons resultados e capacidade de processamento ideal, e vários indicadores de beneficiamento atingiram um nível satisfatório. A aplicação do jigue de separação por gravidade de fluorite é também cada vez mais extensa.

A beneficiação da scheelite baseia-se nas características de disseminação do minério, sendo frequentemente utilizada a combinação de separação por gravidade e flotação. A adição de sais metálicos polivalentes ao vidro de água pode melhorar significativamente o efeito de flotação da scheelite. O teor de sulfureto de metal no minério de fluorite é relativamente elevado e, por vezes, o teor de chumbo e zinco pode atingir o grau industrial. Portanto, ao desenvolver e utilizar, devemos também considerar a recuperação do minério de metal.

Key Takeaways for Maximizing Recovery

Effective separation of scheelite and fluorite relies on a well-designed multi-stage process that combines gravity concentration with selective flotation. By carefully controlling reagents (collectors, depressants, and pH modifiers) and leveraging the differences in specific gravity, operators can significantly improve resource utilization—especially critical for China’s large reserves of associated minerals. For best results, pilot testing is recommended to optimize conditions for specific ore compositions. As demand for these minerals grows, adopting advanced beneficiation techniques will be essential for both economic efficiency and sustainable resource management.

Need further guidance? Consult mineral processing experts to tailor these methods to your ore characteristics.
